TE series LED Street Light
flexible solutions that lead to the shortest payback time. With its long lifespan and limited
maintenance requirements, the TE series enables you to maximise your return on
investment. Available in 4 sizes – with a lumen package scalable up to 35,200lm – and with
numerous lighting distributions, the TE series can meet all your road and urban lighting
needs.
| Model：TE3102-100W | |||
| Nominal Power | 100W | ||
| Luminous Flux | 120-150LM/W | ||
| LED | SMD 3030/5050 | ||
| LED Quantity | 110pcs | ||
| Input Voltage | AC85-265V 50-60Hz | ||
| CCT | 6500K/3200K/4000K optional | ||
The TE series LED street light sets a new benchmark in LED lighting with performing and
flexible solutions that lead to the shortest payback time. With its long lifespan and limited
maintenance requirements, the TE series enables you to maximise your return on
investment. Available in 4 sizes – with a lumen package scalable up to 35,200lm – and with
numerous lighting distributions, the TE series can meet all your road and urban lighting
needs.
The solid aluminum material ensures durability and efficient heat dissipation. The radiator
adopts a hollow design to increase the heat dissipation area, accelerate the airflow,protect the lamp chip, and provide 50,000+ hours of long-lasting lighting
ITEM
TE3101-50W
TE3102-100W
TE3103-150W
TE3104-200W
Input Voltage
AC85-265V,50/60Hz
Lamp Body Size
535*210*110mm
605*265*110mm
710*265*110mm
760*280*110mm
LED Driver
Meanwell/Philips optional
Luminous Flux
110-150LM/W
Material
Aluminium
Certificate
CE/RoHs
Key Components & Advantages
Patented Design
Patents in utility & appearance registered in China.
High-brightness-LED
high quality LED chips distributed in one lamp cap, high brightness
Technical Support
Simulations to show optic performance in real applications, Free for all our customers
Thermal Management
Structure is optimized by advanced FEA technology.
Ajustable angle
Suitable for multiple light distribution scenes
Widely Application
Products are widely used in yard, garden and other areas.
